Overview

The MB Settings Page extension helps you to create one or multiple settings pages for your website. You can use it to create a theme options page, or a settings page for your plugin, or a custom settings page for clients’ websites.

It’s a wrapper of Settings API (provided by WordPress) and Meta Box, that combines the power of both platforms and provides an better and simpler way to create a settings page. Briefly, it helps you create a settings page via a short and beautiful PHP syntax without going through all the low-level functions of the Settings API. Besides it supports all the field types in Meta Box as well as other extensions.

By using Settings API, all the fields’ values will be saved as an array in a single option in the WordPress’s options table. Each field is an element of the array with the corresponding key (field ID). It’s the recommended way by WordPress that doesn’t make your options table bloat.

These are the screenshots:

Tab style (the default WordPress style for settings page):

settings page with tabs

Boxed style (the WordPress style for meta boxes):

settings page boxed style

For more info, please see the extension page.

Installation

Before installing the extension, you need to install Meta Box plugin first.

  1. Go to Plugins → Add New and search for Meta Box
  2. Click Install Now button to install the plugin
  3. After installing, click Activate Plugin to activate the plugin

The extension is just a WordPress plugin, you can install it like a normal WordPress plugin.

  1. Go to Plugins, click Add new, then click Upload plugin.
  2. Choose the .zip file you downloaded and click Install now
  3. After finishing upload, click Activate to finish.

After installing, you need to register a settings page and register meta boxes (and fields) for that settings page.

Quick example

Just copy and paste the code below to your theme’s functions.php file, or your plugin file:

// Register a theme options page
add_filter( 'mb_settings_pages', function ( $settings_pages ) {
    $settings_pages[] = array(
        'id'          => 'pencil',
        'option_name' => 'pencil',
        'menu_title'  => 'Pencil',
        'icon_url'    => 'dashicons-edit',
        'style'       => 'no-boxes',
        'columns'     => 1,
        'tabs'        => array(
            'general' => 'General Settings',
            'design'  => 'Design Customization',
            'faq'     => 'FAQ & Help',
        ),
    );
    return $settings_pages;
} );

// Register meta boxes and fields for settings page
add_filter( 'rwmb_meta_boxes', function ( $meta_boxes ) {
    $meta_boxes[] = array(
        'id'             => 'general',
        'title'          => 'General',
        'settings_pages' => 'pencil',
        'tab'            => 'general',
        'fields' => array(
            array(
                'name' => 'Logo',
                'id'   => 'logo',
                'type' => 'file_input',
            ),
            array(
                'name'    => 'Layout',
                'id'      => 'layout',
                'type'    => 'image_select',
                'options' => array(
                    'sidebar-left'  => 'https://i.imgur.com/Y2sxQ2R.png',
                    'sidebar-right' => 'https://i.imgur.com/h7ONxhz.png',
                    'no-sidebar'    => 'https://i.imgur.com/m7oQKvk.png',
                ),
            ),
        ),
    );
    $meta_boxes[] = array(
        'id'             => 'colors',
        'title'          => 'Colors',
        'settings_pages' => 'pencil',
        'tab'            => 'design',
        'fields' => array(
            array(
                'name' => 'Heading Color',
                'id'   => 'heading-color',
                'type' => 'color',
            ),
            array(
                'name' => 'Text Color',
                'id'   => 'text-color',
                'type' => 'color',
            ),
        ),
    );
    $meta_boxes[] = array(
        'id'             => 'info',
        'title'          => 'Theme Info',
        'settings_pages' => 'pencil',
        'tab'            => 'faq',
        'fields'         => array(
            array(
                'type' => 'custom_html',
                'std'  => 'Having questions? Check out our documentation',
            ),
        ),
    );
    return $meta_boxes;
} );

Now refresh the admin page and you’ll see a new settings page Pencel appeared in the main menu, like this:

settings page with tabs

Creating settings pages

Creating a settings page is done by filter mb_settings_pages. The code to add a settings page looks like this (this registers a theme options page under Appearance menu):

add_filter( 'mb_settings_pages', 'prefix_options_page' );
function prefix_options_page( $settings_pages ) {
    $settings_pages[] = array(
        'id'          => 'theme-slug',
        'option_name' => 'theme_slug',
        'menu_title'  => 'Theme Options',
        'parent'      => 'themes.php',
    );
    return $settings_pages;
}

The filter takes an array of defined settings pages as the argument. The callback function must return an array of settings pages.

Each settings page is defined by an array of the following options:

Name Description
id Page ID. Required. Will be used as the slug in URL and option name (if option_name missed).
option_name Option name where settings data is saved to. Optional. Takes id if missed. If you want to use theme mods, then set this to theme_mods_$themeslug.
menu_title Menu title. Optional. Takes page_title if missed.
page_title Page title. Optional. Takes menu_title if missed. Note: either menu_title or page_title (or both) must have value.
capability Required capability to access the settings page. Optional. Default edit_theme_options.
position Menu position. See position parameter of add_menu_page() function.
parent ID of the parent page. Optional. Can be WordPress menu or custom settings page menu. See examples below for more details.
submenu_title Set this to the default submenu title (first submenu) if the settings page is a top-level menu. Optional.
help_tabs The content displayed when clicking on the Help button on the top right (near the Screen Options button). See below for details.
style How do you want to style the settings page. Supports boxes which has same the style as normal WordPress meta boxes (like in the edit post screen) and no-boxes which has the same style as WordPress settings page. In no-boxes style, each meta box is a section of the settings page.
columns The number of columns in the meta boxes. Can be 1 or 2. You might want to use 1 column with no-boxes style to match WordPress style.
tabs Organized meta boxes and fields in tabs (see the example below). This param takes an array of (tab_id => Tab Title). Note: when using this param, you must specify which tab the meta box belongs by adding a new parameter 'tab' => tab_id. See example below.
submit_button The custom text for submit button. Optional.
message The custom message displayed when saving options. Optional.
customizer Whether to show the settings page in the Customizer as a panel. true or false (default). Optional. See below for details.
customizer_only Whether to show only as a Customizer panel, no admin settings page. true or false (default). Optional.
network Make the settings page network-wide (in multisite environment). true or false (default). Optional.

Examples

This example registers a top-level menu pages and 2 sub settings page:

add_filter( 'mb_settings_pages', function ( $settings_pages ) {
    $settings_pages[] = array(
        'id'            => 'my-options',
        'menu_title'    => 'Options',
        'option_name'   => 'my_options',
        'icon_url'      => 'dashicons-images-alt',
        'submenu_title' => 'Options', // Note this
    );
    $settings_pages[] = array(
        'id'          => 'my-options-im',
        'option_name' => 'my_options',
        'menu_title'  => 'Import',
        'parent'      => 'my-options', // Note this
    );
    $settings_pages[] = array(
        'id'          => 'my-options-ex',
        'option_name' => 'my_options',
        'menu_title'  => 'Export',
        'parent'      => 'my-options',
    );
    return $settings_pages;
} );

Here is the result:

registrer settings pages

Note that:

  • The submenu_title allows us to set the first submenu text which can be different from the top-level menu text.
  • The parent of submenus are set to the ID of top-level menu (my-options).

In case you want to add submenu to existing WordPress pages, set the parent option to:

Value Page
index.php Dashboard
edit.php Posts
upload.php Media
link-manager.php Links
edit.php?post_type=page Pages
edit-comments.php Comments
edit.php?post_type=your_post_type Custom post type
themes.php Apperance
plugins.php Plugins
users.php Uses
tools.php Tools
options-general.php Settings

Help tabs

WordPress has a nice feature that allows us to define instruction, guidelines in the “Help” section of each admin screen. To see the help content, click on the “Help” button on the top right, near the “Screen Options” button. Note that, the button appears only when there’s some help content.

With MB Settings Page, you’re able to define the help content. The content is divided into tabs. To define the tabs and their content, use the following structure:

'help_tabs' => array(
    array(
        'title'   => 'General',
        'content' => '<p>This tab displays the general information about the theme.</p>',
    ),
    array(
        'title'   => 'Homepage',
        'content' => '<p>This tab displays the instruction for setting up the homepage.</p>',
    ),
),

In short, each tab is an array of title and content. You can pass more parameters just like the add_help_tab() function. However, the title and content are the most important parameters and they’re required.

Then when clicking “Help” button, you’ll see:

wordpress admin page help tabs

Creating settings fields

Creating settings meta boxes and fields for settings pages is the same as for posts. You need to hook to rwmb_meta_boxes and set a param settings_pages to the settings page(s) you want to add to.

The sample code is below:

add_filter( 'rwmb_meta_boxes', function ( $meta_boxes ) {
    $meta_boxes[] = array(
        'id'             => 'general',
        'title'          => 'General',
        'settings_pages' => 'theme-slug',
        'fields'         => array(
            array(
                'name' => 'Logo',
                'id'   => 'logo',
                'type' => 'file_input',
            ),
            array(
                'name'    => 'Layout',
                'id'      => 'layout',
                'type'    => 'image_select',
                'options' => array(
                    'sidebar-left'  => 'https://i.imgur.com/Y2sxQ2R.png',
                    'sidebar-right' => 'https://i.imgur.com/h7ONxhz.png',
                    'no-sidebar'    => 'https://i.imgur.com/m7oQKvk.png',
                ),
            ),
        ),
    );
    $meta_boxes[] = array(
        'id'             => 'colors',
        'title'          => 'Colors',
        'settings_pages' => 'theme-slug',
        'fields'         => array(
            array(
                'name' => 'Heading Color',
                'id'   => 'heading-color',
                'type' => 'color',
            ),
            array(
                'name' => 'Text Color',
                'id'   => 'text-color',
                'type' => 'color',
            ),
        ),
    );
    $meta_boxes[] = array(
        'id'             => 'info',
        'title'          => 'Theme Info',
        'context'        => 'side',
        'settings_pages' => 'theme-slug',
        'fields'         => array(
            array(
                'type' => 'custom_html',
                'std'  => 'A responsive theme for businesses and agencies.',
            )
        ),
    );
    return $meta_boxes;
} );

Note:

  • You must set settings_pages to the ID of the settings page. If you want to add meta boxes to 2 or more settings pages, set it to an array of settings pages’ IDs
  • All fields settings stay unchanged.
  • The settings page uses 2 columns layout, which mimic WordPress post screen and the value for context has the same meaning.

Using tabs

The example below registers 1 top level settings page with 3 tabs. Each tabs has one meta box. The style is set to no-boxes and columns is set to 1 to match WordPress style:

add_filter( 'mb_settings_pages', function ( $settings_pages ) {
    $settings_pages[] = array(
        'id'          => 'pencil',
        'option_name' => 'pencil',
        'menu_title'  => 'Pencil',
        'icon_url'    => 'dashicons-edit',
        'style'       => 'no-boxes',
        'columns'     => 1,
        'tabs'        => array(
            'general' => 'General Settings',
            'design'  => 'Design Customization',
            'faq'     => 'FAQ & Help',
        ),
    );
    return $settings_pages;
} );

add_filter( 'rwmb_meta_boxes', function ( $meta_boxes ) {
    $meta_boxes[] = array(
        'id'             => 'general',
        'title'          => 'General',
        'settings_pages' => 'pencil',
        'tab'            => 'general',
        'fields' => array(
            array(
                'name' => 'Logo',
                'id'   => 'logo',
                'type' => 'file_input',
            ),
            array(
                'name'    => 'Layout',
                'id'      => 'layout',
                'type'    => 'image_select',
                'options' => array(
                    'sidebar-left'  => 'https://i.imgur.com/Y2sxQ2R.png',
                    'sidebar-right' => 'https://i.imgur.com/h7ONxhz.png',
                    'no-sidebar'    => 'https://i.imgur.com/m7oQKvk.png',
                ),
            ),
        ),
    );
    $meta_boxes[] = array(
        'id'             => 'colors',
        'title'          => 'Colors',
        'settings_pages' => 'pencil',
        'tab'            => 'design',
        'fields' => array(
            array(
                'name' => 'Heading Color',
                'id'   => 'heading-color',
                'type' => 'color',
            ),
            array(
                'name' => 'Text Color',
                'id'   => 'text-color',
                'type' => 'color',
            ),
        ),
    );
    $meta_boxes[] = array(
        'id'             => 'info',
        'title'          => 'Theme Info',
        'settings_pages' => 'pencil',
        'tab'            => 'faq',
        'fields'         => array(
            array(
                'type' => 'custom_html',
                'std'  => 'Having questions? Check out our documentation',
            ),
        ),
    );
    return $meta_boxes;
} );

Here is the result:

settings page with tabs

Important: When using tabs, you must define tab attribute for all meta boxes to make them appear in corresponding tabs. Missing tab attribute makes the meta boxes hidden.

Creating Customizer Settings

This is a quick video that demonstrate how to use MB Settings Page to create custom panels, sections and fields in the Customizer. You’ll see how easy it is to turn a settings page into a Customizer panel.

Creating A Customizer Panel

The idea behind Customizer support is map a settings page to a Customizer panel. And each meta box in the settings page will be a Customizer section. The mapping is quite simple, clear, but very powerful. It allows you to bring everything in a settings page into the Customizer with a single line of code.

Assuming you have a settings page, registered with this code:

add_filter( 'mb_settings_pages', function ( $settings_pages ) {
    $settings_pages[] = array(
        'id'          => 'rubik',
        'option_name' => 'theme_mods_justread',
        'menu_title'  => 'Theme Options',
        'parent'      => 'themes.php',
    );
    return $settings_pages;
} );

To bring it to the Customizer, simply add 'customizer' => true, e.g.:

add_filter( 'mb_settings_pages', function ( $settings_pages ) {
    $settings_pages[] = array(
        'id'          => 'rubik',
        'option_name' => 'theme_mods_justread',
        'menu_title'  => 'Theme Options',
        'parent'      => 'themes.php',
        'customizer'  => true, // THIS
    );
    return $settings_pages;
} );

And you’ll see a new panel in the Customizer as follows:

A new panel in the Customizer

And each meta box in the settings page now are the Customize section:

Meta boxes become Customize sections

Disabling Admin Settings Pages

When you have Customizer panels, sections and fields, you might not want to use settings pages in the WordPress admin anymore. The Customizer now becomes the all-in-one place for entering the settings and customization.

Understanding it, we added a new parameter ‘customizer_only’ => true that disables the admin settings page and allows only Customizer settings:

add_filter( 'mb_settings_pages', function ( $settings_pages ) {
    $settings_pages[] = array(
        'id'               => 'rubik',
        'option_name'      => 'theme_mods_justread',
        'menu_title'       => 'Theme Options',
        'parent'           => 'themes.php',
        'customizer'       => true,
        'customizer_only'  => true, // THIS
    );
    return $settings_pages;
} );

Creating Top-Level Customizer Sections

Sometimes you don’t want the top-level panel that creates too much hierarchy (panel → sections → fields). You just want top-level sections (sections → fields). That will help users to navigate to your settings in the Customizer faster and easier.

In that case, you need to do 2 steps:

Step 1: Remove the code that registers settings pages as you don’t need settings pages anymore. This is the code you should remove:

add_filter( 'mb_settings_pages', function ( $settings_pages ) {
    $settings_pages[] = array(
        'id'          => 'rubik',
        'option_name' => 'theme_mods_justread',
        'menu_title'  => 'Theme Options',
        'parent'      => 'themes.php',
        'customizer'  => true,
    );
    return $settings_pages;
} );

Step 2: In each meta box, replace the parameter 'settings_pages' => 'rubik' with 'panel' => ''.

For example, you have a meta box for your settings page, which has the following code:

add_filter( 'rwmb_meta_boxes', function ( $meta_boxes ) {
    $meta_boxes[] = array(
        'id'             => 'general',
        'title'          => 'General',
        'settings_pages' => 'rubik',
        'fields'         => array(
            array(
                'name' => 'Logo',
                'id'   => 'logo',
                'type' => 'file_input',
            ),
            array(
                'name'    => 'Layout',
                'id'      => 'layout',
                'type'    => 'image_select',
                'options' => array(
                    'sidebar-left'  => 'http://i.imgur.com/Y2sxQ2R.png',
                    'sidebar-right' => 'http://i.imgur.com/h7ONxhz.png',
                    'no-sidebar'    => 'http://i.imgur.com/m7oQKvk.png',
                ),
            ),
        ),
    );
    return $meta_boxes;
} );

Then you need to change it to:

add_filter( 'rwmb_meta_boxes', function ( $meta_boxes ) {
    $meta_boxes[] = array(
        'id'             => 'general',
        'title'          => 'General',
        'panel'          => '', // THIS
        'fields'         => array(
            array(
                'name' => 'Logo',
                'id'   => 'logo',
                'type' => 'file_input',
            ),
            array(
                'name'    => 'Layout',
                'id'      => 'layout',
                'type'    => 'image_select',
                'options' => array(
                    'sidebar-left'  => 'http://i.imgur.com/Y2sxQ2R.png',
                    'sidebar-right' => 'http://i.imgur.com/h7ONxhz.png',
                    'no-sidebar'    => 'http://i.imgur.com/m7oQKvk.png',
                ),
            ),
        ),
    );
    return $meta_boxes;
} );

It’s very simple, isn’t it? And you’ll see the section on the Customizer like this:

Sections now appear as top-level in the Customizer

What if you want the section to be inside another panel? Like inside another plugin’s panel? Simply set the panel parameter to ID of the target panel: 'panel' => 'panel_id'.

Compatibility

At the moment, all Meta Box fields are supported in the Customizer, except file and image field types. But other upload field types such as file_advanced, file_upload, image_advanced, image_upload, single_image still work very well. (The reason is that the Customizer doesn’t handle file uploads and the submission is performed via Ajax)

The good news is all the extensions such as Meta Box Conditional Logic, Meta Box Tabs are supported. That will help you create much better experiences for your users.

Known issues: because of the complexity, the postMessage transport for the Customizer is not supported yet. Your browser will refresh the whole page to see the updated settings.

Creating Network Settings Pages

A network settings page is a settings page that provide settings for all the websites in the network (multisite environment). For example, you might want to enter Google Maps API key for all the websites, or set the contact phone number for all of them.

Sample network settings page

Using MB Settings Page, you’re now able to do that easily with just one line of code. Simply add 'network' => true to the settings pages args. Like this:

add_filter( 'mb_settings_pages', function ( $settings_pages ) {
    $settings_pages[] = array(
        'id'          => 'custom-options',
        'option_name' => 'custom_options',
        'menu_title'  => 'Custom Options',
        'icon_url'    => 'dashicons-welcome-widgets-menus',
        'network'     => true, // THIS
    );

    return $settings_pages;
} );

Don’t forget to network activate Meta Box and MB Settings Pages. And now, when you go to network admin area, you’ll see a settings page like the screenshot above.

Hooks

mb_settings_page_load action

This action fires when a settings page is loaded. It’s used internally to:

  • Register meta boxes and custom fields in the settings page, and
  • Save the submitted data.

These actions use the default priority 10. So you can hook to this action to do something after the data is saved with a higher priority (like 20):

add_action( 'mb_settings_page_load', function ( $args ) {
    if ( $args['id'] === 'YOUR SETTINGS PAGE ID' ) {
        // Do something
    }
}, 20 );

mb_settings_page_submit_buttons action

This action fires after the submit button is rendered, which allows you to add more custom buttons next to the submit button.

Data

Settings values are saved in WordPress option as an array with the option name is option_name in the settings page configuration. The keys of that array are the field IDs and values are the field values.

It’s the recommended way by WordPress that doesn’t make your options table bloat.

Getting field value

You’re able to use helper function rwmb_meta() to get field value as follows:

$value = rwmb_meta( $field_id, ['object_type' => 'setting'], $option_name );
echo $value;

For network settings, please use the following code:

$value = rwmb_meta( $field_id, ['object_type' => 'network_setting'], $option_name );
echo $value;

Notes:

  • In the 2nd parameter, you need to pass 'object_type' => 'setting' or 'object_type' => 'network_setting', and
  • In the last parameter, you need to pass the option name for the settings page

Other parameters are the same as for posts. Please see this documentation for details.

It requires the extension version 1.2+ to use the helper function. If you’re using an older version, please update now.

In case you use an older version than 1.2, you can get the settings manually:

$settings = get_option( 'option_name' );
$field_id = 'your_field_id';
if ( isset( $settings[$field_id] ) ) {
    return $settings[$field_id];
}

Note that this code returns only raw data of field value. It doesn’t return meaningful information for images, file, etc. To do that, please add a small piece of code as follow:

// Getting images
$settings = get_option( 'option_name' );
$image_ids = $settings['images'];
foreach ( $image_ids as $image_id ) {
    $image = RWMB_Image_Field::file_info( $image_id, array( 'size' => 'thumbnail' ) );
    echo '<img src="' . $image['url'] . '">';
}

These are some helper functions that you can use to retrieve more info:

Field type Helper function(s)
image, image_advanced, plupload_image, thickbox_image wp_get_attachment_image_src()
  wp_get_attachment_image_url()
  RWMB_Image_Field::file_info( $image_id, $args ); (where $args is an array and accepts only size attribute)
file, file_advanced get_attached_file()
  RWMB_File_Field::file_info( $image_id );
oembed RWMB_OEmbed_Field::get_embed( $url );
taxonomy, taxonomy_advanced get_term()
user get_userdata()
post get_post()

Read more on how field values are saved into the database.

Improve this page
